150 mm

78 mm

37 mm

*The depth is the thickness of the equipment outside the wall. Actual dimensions may vary depending on configuration, manufacturing process, and measurement method.

About 240 g

*The actual weight may vary slightly according to configuration, manufacturing process, and measurement method.

WiFi 6

2.4 GHz
574 Mbps (theoretical value)
5 GHz
2402 Mbps (theoretical value)
Total theoretical negotiated rate: 2976 Mbps

*Maximum wireless rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual data throughput will vary and be lowered by network, your country’s regulation, and environmental conditions, including network traffic volume, device limitations, and building construction.

2.4 GHz & 5 GHz (support dual band integration configuration)

2.4 GHz: Up to 128
5 GHz Wi-Fi: Up to 128
Dual bands allows 128 devices simultaneously

*The maximum number is a theoretical value and the actual value prevails. The Wi-Fi network can be configured as a main network or a guest network. The maximum number of concurrent access devices is the total accessed device number of the main network and guest network.

2.4 GHz: 2 antennas;
5 GHz: 2 antennas

128 MB RAM + 128 MB ROM

*The available memory capacity may be less because the software occupies some space.

1 × 10/100/1000 Mbps adaptive rate Ethernet ports

1 status indicator for 2.4G, 1 status indicator for 5G,
with three colors (red, yellow, green)

Supported (WPA2-PSK, WPA/WPA2-PSK, WPA2-PSK/WPA3-SAE, and blocklist/trustlist)

0℃ to 40℃ (32°F–104°F)

5% to 95% RH, non-condensing

–40℃ to +70℃ (–40℉ to +158℉)

< 12 W

Supports HUAWEI Mesh+ and 802.11kvr protocol, AP mode, HUAWEI AI Life App Remote Management, IPv4/IPv6, WPA3, one-press networking(WPS)

about 350 g (Package included)

*The actual weight may vary slightly according to configuration, manufacturing process, and measurement method.
